Manufacturer: TDK
Product type: Power inductor (SMD type)
RoHS:
Type: Power Conductor
Package/Box: 5 mm x 5 mm x 2.4 mm
Shielded:
Inductance: 10 uH
Tolerance: 20%
Maximum DC current: 2.14 A
Maximum DC resistance: 92 mOhms
Saturation current: 880 mA
Minimum operating temperature: -40 ° C
Maximum operating temperature:+105 ° C
Terminal: Standard
Length: 5mm
Width: 5mm
Height: 2.4 mm
Core material: Ferrite
Series: VLCF
Encapsulation: Reel
Encapsulation: Cut Tape
Package: MouseReel
Application: Commercial
Trademark: TDK
Kernel type: Wirewound
Installation style: PCB Mount
Product: Power Conductors
Product Type: Power Conductors - SMD
500
Subcategory: Inductors, Chokes&Coils
End connection type: SMD/SMT
Test frequency: 100 kHz
Part number alias: VLCF5024T-100MR88-2-
Unit weight: 221 mg
